Weinig Unimat Super 4 four-sided planer

Technical Data: - Manufacturer: Weinig - Type: Unimat Super 4 - Year of Manufacture: 2003 - Working Width: 25 - 150 mm - Working Height: 15 - 50 mm - Shaft Arrangement: Spindle 1 (bottom): Planing and milling of the guide groove 125x40x40 mm, Z=2 125x120x40 mm, Z=2 Spindle 2 (top): Combination tool consisting of a special planer head with guide groove and two face cutters. Precise thickness planing and face milling of the gluing surfaces on the right and left. Right face mill: 240x17x40mm, Z=8 Special planer head: 125x240x40mm, Z=4 Left face mill: 240x80x122mm, Z=8 Tool circle diameters: 125 and 250mm Spindle 3 (bottom): Removing the guide slot and finish planing. 125x170x40mm, Z=4 - Spindle 1: 11 kW - Spindle 2: 18.5 kW - Spindle 3: 5.5 kW - Feed rate: 2.2 kW - Feed rate: 5-20 m/min. - Spindle speed 1 and 3: 6,000 rpm. - Spindle speed 2: 7,000 rpm. - Transport roller diameter (hardened): 140 mm - Infeed table length: 2,000 mm - Machine tables: hardened - Guide groove in machine table - Extraction ports: 2 x 140 mm, 1 x 160 mm - Airflow: approx. 5,500 m³/h - Voltage/Hz: 400/50 - Location: Blomberg warehouse from January 2026
