Pos.1 VEN CLEAN Smart Debris Removal Compressed air dust removal to clean the parts to be painted from dust on profiled workpiece surfaces. There are five rotating blast stars installed. These detach the dust from the surface. The dissolved dust is suctioned on both sides by suction shafts. External suction is required on the customer side. Technical data: Length: 2,060 mm Roller spacing: 85 mm Working width: 1,300 mm Total width: 1,800 mm Drive power: 0.25 kW Exhaust air volume: 4,000 m³/h To be provided by customer Compressed air consumption: 980 Nl/min. Ionization as nozzle rod, not EX) with Compressed air nozzles, Compressed air consumption 840 L/min. Pos. 2 Spray automat VEN SPRAY Comfort - Manufacturer Venjakob - Type: VEN SPRAY Comfort CNC 7000 - Year of construction 2017 - Length: 4,350 mm - Working height approx. 930 mm +/- 20 mm - Working width 1,300 mm - Operating side left - Price for refurbished machine - As-is condition, machine not refurbished - Gun drive in duo arrangement - Dry suction - Diameter of suction connection 500 mm - Exhaust air capacity 10,000 m³/h - Belt transport system - Feed rate steplessly adjustable ~ 2-6 m/min - With belt cleaning system with scraper in tungsten carbide version Here is a complete pre-installation for retrofitting a second washer available. - Gun control, Touch Screen CNC7000 - Installed color circuits 1 pc. (optional others possible) - Supply air cover - Suitable for water-based paints - Suitable for solvent-based paints - Length: 4,350 mm + (2,060 mm) - Width: 3,540 mm - Height: 2,600 + 440 mm - Control cabinet, freestanding - Electrical connection 23.33 kW / 63 A - Volts, Hz 400 / 50 - Color RAL 7035 - Location, in stock - Voltage fluctuations max. +/- 5 % ___________________________________ Optional we can also provide an offer for installation and commissioning of the system, as well as instruction of the employees. If desired we also offer regular maintenance and servicing of the machine. For more information, just contact us!
