Cefla FVN 3/5500/190/24 high dryer
Sold
Cefla FVN 3/5500/190/24 high dryer
Location:North Rhine-Westphalia, Germany
Description
- Infeed and outfeed on the same side, u-form
- Measure: middle pallet - middle pallet : 3.660 mm
- Location, not in stock
- Without control valves and water pumps
Specifications
| Manufacturer | Cefla |
| Model | FVN 3/5500/190/24 |
| Year | 1999 |
| Condition | Used |
| Stock Number | 0,00 |
| Product code | 3306228 |
| Working width | 1300 mm |
| Pallet length | 5.500 mm |
| Useable pallet length | 5.200 mm |
| Pallet number | 24 pcs. |
| Number of useable pallet | 22 pcs. |
| Max. part height | 110 mm |
| Heat output | 3x84 KW / 3x72.000 kcal/h |
| Feed speed | 3-10 m/min |
| Total connection power | 18,8 kW |
| Voltage / hz | 400 / 50 |
| Clearance height between the pallet | 120 mm |
| Number of adjustable temperature zone | 3 pcs. |
| Width | 5.967 mm |
| Length | 7.615 mm |
| Height | 3,345 mm (4,000) mm |
| Fresh air | 12.000-18.000 m³/h |
